Global Power

Model GPS 12100B

$399.95 USD

12.8V 100Ah

LITHIUM IRON PHOSPHATE BATTERY

ELECTRICAL SPECIFICATIONS
Nominal Voltage 12.8V
Nominal Capacity 100Ah
Capacity@20A 5 Hours
Energy 1280Wh
Resistance < 20mΩ @ 50% SOC
Efficiency 99%
Self Discharge <3% Per Month
Maximum Modules in Series and Parallel 4series / 4Parallels
DISCHARGE SPECIFICATIONS
Maximum Continuous Discharge Current 100A
Peak Discharge Current 200A < 3s
BMS Discharge Current Cut-off 300A ± 20A[90 ± 10ms]
Recommend Low Voltage Disconnect 10V
BMS Discharge Voltage Cut-off 10V[2.2 ± 0.08vpc] [100 ± 50ms]
Reconnect Voltage10V [3.0 ± 0.1vpc]
Short Circuit Protection 200-350s
TEMPERATURE SPECIFICATIONS
Discharge Temperature -4 to 140°F [-20 to 60°C]
Charge Temperature 32 to 113°F [0 to 45°C]
Storage Temperature 23 to 95°F[-5 to 35°C]
High Temperature Cut-off Discharge 149°F [65°C] [Customized
Reconnect Temperature 122°F [50°C] [Customized]
Low Temperature Cut-off Charge 32°F [0°C] [Customized]
High Temperature Cut-off Charge 129.2°F [54°C] [Customized]
MECHANICAL SPECIFICATIONS
Dimensions [L*W*H] 13*7.1*9.5 in
Weight 32.6lbs
Terminal Type M8 screw
Case Material ABS
Enclosure Protection IP65
Cell Type Cylindrical
Chemistry LiFePo4
Configuration 4S1P
CHARGER SPECIFICATIONS
Remommend Charge Current 10A-30A
Maximum Charge Current 100A
Recommend Charge Voltage 13.8V - 14.4V
BMS Charge Voltage Cut-off 14.6V[3.65 ± 0.1V]
Reconnect Voltage 14.6V[3.65 ± 0.1V]
COMPLIANCE SPECIFICATIONS
Commnunication NO
Certifications CE,ROHS,MSDS,UN38.3
Shipping Classifiction UN3480,CLASS9
